Kingston 16GB, DDR4, 3200MHz (PC4-25600), CL22, DIMM Memory
Kingston 16GB, DDR4, 3200MHz (PC4-25600), CL22, DIMM Memory
€39.72 incl. Vat
50 in stock
Description
ValueRAM’s KVR32N22D8/32 is a 4G x 64-bit (32GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM), 2Rx8, memory module, based on sixteen 2G x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-3200 timing of 22-22-22 at 1.2V. Each 288-pin DIMM uses gold contact fingers.
- Power Supply: VDD = 1.2V Typical
- VDDQ = 1.2V Typical
- VPP = 2.5V Typical
- VDDSPD = 2.2V to 3.6V
- Nominal and dynamic on-die termination (ODT) for data, strobe, and mask signals
- Low-power auto self refresh (LPASR)
- Data bus inversion (DBI) for data bus
- On-die VREFDQ generation and calibration
- Dual-rank
- On-board I2 serial presence-detect (SPD) EEPROM
- 16 internal banks; 4 groups of 4 banks each
- Fixed burst chop (BC) of 4 and burst length (BL) of 8 via the mode register set (MRS)
- Selectable BC4 or BL8 on-the-fly (OTF)
- Fly-by topology
- Terminated control command and address bus
- PCB: Height 1.23” (31.25mm)
- RoHS Compliant and Halogen-Free
Description
Specification
- Series: Kingston ValueRAM
- DDR Type: DDR4
- Size: 1 x 16GB
- #Hide#Individual Module Size: 16GB
- #Hide#Total Capacity: 16GB Total
- Speed: 3200 MHz
- Compliance: PC4-25600
- Pins: 288-pin
- CAS Latency: CL22
- Data Integrity Check: Non-ECC
- Voltage: 1.2V
- Timings: 22-22-22
- Heatsink: No
- #Hide#LED Lighting: No
- Additional Information: See Overview
- Package Type: Blister Pack
- Package Weight: 0.0225 kg
- Warranty: Lifetime
Additional information
| Weight | 0.0225 kg |
|---|---|
| EAN |
