TP-LINK (TL-SG1005P) 5-Port Gigabit Unmanaged Desktop Switch, 4 Port PoE+, Steel Case

Add to wishlist
Compare

TP-LINK (TL-SG1005P) 5-Port Gigabit Unmanaged Desktop Switch, 4 Port PoE+, Steel Case

Add to wishlist
Compare

€60.53 incl. Vat

87 in stock

SKU: SWI-5TPPOE1000 Category: Tag:

Description

  • 5 10/100/1000Mbps RJ45 ports
  • With four PoE ports, transfers data and power on one single cable
  • Working with IEEE 802.3af compliant PDs, expands home and office network
  • 802.1p/DSCP QoS enable smooth latency-sensitive traffic
  • Requires no configuration and installation



What This Product Does

TL-SG1005P is a 5 10/100/1000Mbps ports unmanaged switch that requires no configuration and provides 4 PoE+ (Power over Ethernet) ports. It can automatically detect and supply power with all IEEE 802.3af compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.




Power over Ethernet

4 of the 5 Auto-Negotiation RJ45 ports (Port 1 to Port 4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).




Overload Arrangement

TL-SG1005P has the priority function which will help protect the system when the system power is overloaded. If all PoE PDs power consumption is >= 56W, a priority will be arranged among the PoE ports, then the system will cut off the power of the lowest-priority port.




Port Priority Function

Priority (Port 1=Port 2=Port 3>Port 4): This function will help to ensure the normal operation of the system, it means Port 4 will be cut off when all total PoE PDs power consumption exceed 56W. For an example, Port 1, 2 and 4 is using 15.4W (maximum power for per port is 15.4W); the system power is 46.2W in total. If there is an additional PD inserted to Port 3 with 10W, and then the system will cut off the power of Port 4 because of the overloaded power, this means Port 1, 2 will use 15.4W, and Port3 will use 10W, no power will be supplied to Port 4.




Easy To Use

TL-SG1005P is easy to install and use. It requires no configuration and installation. With desktop design, outstanding performance and quality, the TP-Link’s TL-SG1005P 5-Port Gigabit Desktop Switch with 4-Port PoE is an ideal choice for expanding your home or office network.

Description

Specification

  • Rackmountable: No
  • Managed: No
  • Number of Ports: 5
  • Max RJ45 Transfer Rate: 10/100/1000 Mbps
  • Interface(s): 5 x 10/100/1000Mbps RJ45 Ports
    AUTO Negotiation/AUTO MDI/MDIX
  • PoE Ports (RJ45): Standard: 802.3 af compliant
    PoE+ Ports: Port1- Port4
    Power Supply: 56W
  • Bandwidth: 10Gbps
  • Power Supply: External Power Adapter (Output: 48VDC / 1.25A)
  • Dimensions: 3.9 x 3.9 x 1.0 in. (99.8 x 98 x 25 mm)
  • Transfer Method: Store-And-Forward
  • Mac Address Table: 2K
  • Additional Features: Compatible With IEEE 802.3af Compliant PDs
    Priority Function
    Mac Address Auto-Learning And Auto-Aging
    EEE802.3x Flow Control
    802.1p/DSCP QoS
    IGMP Snooping
  • Environment: Operating Temperature: 0C~40C (32F~104F)
    Storage Temperature: -40C~70C (-40F~158F)
    Operating Humidity: 10%~90% non-condensing
    Storage Humidity: 5%~90% non-condensing
  • Package Contents: TL-SG1005P
    Power Adapter
    Installation Guide
  • Package Type: Retail
  • Package Weight: 0.8000 kg
  • Warranty: Limited Lifetime
  • #Hide#POE: Yes

Additional information

Weight 0.8000 kg
